Gebouwd vanaf 1977: 14 stuks
| Hull Type: |
Fin w/spade rudder |
Rig Type: |
Masthead Sloop |
| LOA: |
42.75′ / 13.03m |
LWL: |
34.33′ / 10.46m |
| Beam: |
12.50′ / 3.81m |
Listed SA: |
876 ft2 / 81.38 m2 |
| Draft (max.) |
7.25′ / 2.21m |
Draft (min.) |
|
| Disp. |
21000 lbs./ 9526 kgs. |
Ballast: |
10800 lbs. / 4899 kgs. |
| SA/Disp.: |
18.49 |
Bal./Disp.: |
51.43% |
Disp./Len.: |
231.71 |
| Designer: |
Doug Peterson |
| Builder: |
Jeremy Rogers (UK) |
| Construct.: |
FG |
Bal. type: |
Lead |
| First Built: |
1977 |
Last Built: |
|
# Built: |
|
| AUXILIARY POWER (orig. equip.) |
| Make: |
Seapanther |
Model: |
|
| Type: |
Diesel |
HP: |
30 |
| TANKS |
| Water: |
70 gals. / 265 ltrs. |
Fuel: |
20 gals. / 76 ltrs. |
| RIG DIMENSIONS KEY |
| I: |
57.00′ / 17.37m |
J: |
18.33′ / 5.59m |
| P: |
51.50′ / 15.70m |
E: |
13.75′ / 4.19m |
| PY: |
|
EY: |
|
| SPL: |
|
ISP: |
|
| SA(Fore.): |
522.41 ft2 / 48.53 m2 |
SA(Main): |
354.06 ft2 / 32.89 m2 |
| Total(calc.)SA: |
876.47 ft2 / 81.42 m2 |
DL ratio: |
231.71 |
| SA/Disp: |
18.49 |
Est. Forestay Len.: |
59.87′ / 18.25m |
| BUILDERS (past & present) |
| More about & boats built by: |
Jeremy Rogers Ltd. |
| DESIGNER |
| More about & boats designed by: |
Doug Peterson |
| NOTES |
Available as a flush deck racer or cruiser-racer with coach roof.
Thanks to original builders, Jeremy Rogers Ltd., for supplying updated information on this yacht. |
|
