Gebouwd vanaf 1974: 70 stuks
BN 1 – Gunboots – Winnaar One Ton Cup 1974
| Hull Type: | Fin w/spade rudder | Rig Type: | Masthead Sloop | |||
| LOA: | 35.50′ / 10.82m | LWL: | 29.50′ / 8.99m | |||
| Beam: | 11.42′ / 3.48m | Listed SA: | 623 ft2 / 57.88 m2 | |||
| Draft (max.) | 6.33′ / 1.93m | Draft (min.) | ||||
| Disp. | 13500 lbs./ 6124 kgs. | Ballast: | 6900 lbs. / 3130 kgs. | |||
| SA/Disp.: | 17.64 | Bal./Disp.: | 51.11% | Disp./Len.: | 234.76 | |
| Designer: | Doug Peterson | |||||
| Builder: | Jeremy Rodgers (UK) | |||||
| Construct.: | FG | Bal. type: | Lead | |||
| First Built: | 1974 | Last Built: | # Built: | 80 | ||
| RIG DIMENSIONS KEY | ||||||
| I: | 48.50′ / 14.78m | J: | 15.50′ / 4.72m | |||
| P: | 43.00′ / 13.11m | E: | 11.50′ / 3.51m | |||
| PY: | EY: | |||||
| SPL: | ISP: | |||||
| SA(Fore.): | 375.88 ft2 / 34.92 m2 | SA(Main): | 247.25 ft2 / 22.97 m2 | |||
| Total(calc.)SA: | 623.13 ft2 / 57.89 m2 | DL ratio: | 234.76 | |||
| SA/Disp: | 17.65 | Est. Forestay Len.: | 50.92′ / 15.52m | |||
| BUILDERS (past & present) | ||||||
| More about & boats built by: | Jeremy Rogers Ltd. | |||||
| DESIGNER | ||||||
| More about & boats designed by: | Doug Peterson | |||||
| NOTES | ||||||
|
||||||
